HEIDENHAIN TNC 620 User Manual

Tables and Overviews | Functions of the TNC 620 and the iTNC 530 compared
20
820
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Comparison: Probing system cycles for automatic
workpiece control
Cycle TNC 620 iTNC 530
0 REF. PLANE
X, option 17 X
1 POLAR PRESET
X, option 17 X
2 CALIBRATE TS
– X
3 MEASURING
X, option 17 X
4 MEASURING IN 3-D
X, option 17 X
9 CALIBRATE TS LENGTH
– X
30 CALIBRATE TT
X, option 17 X
31 CAL. TOOL LENGTH
X, option 17 X
32 CAL. TOOL RADIUS
X, option 17 X
33 MEASURE TOOL
X, option 17 X
400 BASIC ROTATION
X, option 17 X
401 ROT OF 2 HOLES
X, option 17 X
402 ROT OF 2 STUDS
X, option 17 X
403 ROT IN ROTARY AXIS
X, option 17 X
404 SET BASIC ROTATION
X, option 17 X
405 ROT IN C AXIS
X, option 17 X
408 SLOT CENTER PRESET
X, option 17 X
409 RIDGE CENTER PRESET
X, option 17 X
410 PRESET INSIDE RECTAN
X, option 17 X
411 PRESET OUTS. RECTAN
X, option 17 X
412 PRESET INSIDE CIRCLE
X, option 17 X
413 PRESET OUTS. CIRCLE
X, option 17 X
414 PRESET OUTS. CORNER
X, option 17 X
415 PRESET INSIDE CORNER
X, option 17 X
416 PRESET CIRCLE CENTER
X, option 17 X
417 PRESET IN TS AXIS
X, option 17 X
418 PRESET FROM 4 HOLES
X, option 17 X
419 PRESET IN ONE AXIS
X, option 17 X
420 MEASURE ANGLE
X, option 17 X
421 MEASURE HOLE
X, option 17 X
422 MEAS. CIRCLE OUTSIDE
X, option 17 X
423 MEAS. RECTAN. INSIDE
X, option 17 X
424 MEAS. RECTAN. OUTS.
X, option 17 X
425 MEASURE INSIDE WIDTH
X, option 17 X
426 MEASURE RIDGE WIDTH
X, option 17 X
427 MEASURE COORDINATE
X, option 17 X

HEIDENHAIN TNC 620 Specifications

General

Power Supply	24 V DC
Control Type	CNC
Axes	Up to 5 axes
Display	15" TFT color flat-panel display
Interfaces	Ethernet, USB
Data Transfer	Ethernet, USB
Hard Drive	SSD
Storage	SSD
