Item Description
Drive Capacity Physical drive capacity (GB or TB)
Drive Version Firmware version of the drive
DKB1 Name of the DKB1 which controls the physical devices
DKB2 Name of the DKB2 which controls the physical devices
Serial Number# Serial product number of the physical devices
■
yy: year (last 2 digits)
■
mm: month (2 digits)
■
xxxxxxxx: pr
oduct number of the physical devices
RAID Level RAID level of the physical devices
■
RAID1(2D+2D)
■
RAID5(7D+1P)
■
RAID6(6D+2P)
■
RAID6(14D+2P)
RAID Concatenation#0 Number indicating a parity group #0 connected to this parity group
Output example: 2-1, 3-1, 4-1
RAID Concatenation#1 Number indicating a parity group #1 connected to this parity group
Output example: 2-1, 3-1, 4-1
RAID Concatenation#2 Number indicating a parity group #2 connected to this parity group
Output example: 2-1, 3-1, 4-1
Resource Group Name Name of resource group to which the parity group of physical devices
belong
Resource Group ID ID (0 to 1023 binary)
Encryption Enable or disable status of the parity group to which the physical devices
belong
■
Enabled: Encryption is enabled.
■
Disabled: Encryption is disabled.
Ports report
The following gure shows an example of part of a ports report. The actual report
includes se
veral more columns of information. The table following the gure describes
the items in the report.
Ports report
Appendix A: Examples of storage conguration reports
System Administrator Guide for VSP Gx00 models and VSP Fx00 models 219
