HP MSR SERIES User Manual

112
Configuring 802.11n MCS
Configuration of mandatory and supported 802.11n rates is achieved by specifying the maximum
Modulation and Coding Scheme (MCS) index.
Select Interface Setup > Wireless > Radio from the navigation tree, and click the Rate tab
Figure 105 Setting 802.11n rate
Table 62 Configuration items
Item Descri
p
tion
Mandatory Maximum MCS
Set the maximum MCS index for 802.11n mandatory rates.
IMPORTANT:
If you select the client dot11n-only option, you must configure the mandatory
maximum MCS.
Multicast MCS
Set the multicast MCS for 802.11n.
The multicast MCS is adopted only when all the clients use 802.11n. If a non
802.11n client exists, multicast traffic is transmitted at a mandatory MCS data
rate.
IMPORTANT:
When the multicast MCS takes effect, the corresponding data rates defined for
20 MHz are adopted no matter whether the 802.11n radio operates in 40 MHz
mode or in 20 MHz mode.
Supported Maximum MCS Set the maximum MCS index for 802.11n supported rates.
For more information about MCS, see WLAN Configuration Guide in HP MSR Router Series
Configuration Guides (V5).
Make the MCS configuration the same on all APs in mesh configuration.
Displaying radio
Displaying WLAN services bound to a radio
Select Interface Setup > Wireless > Summary from the navigation tree, click the Radio tab, click the
specified radio unit, and select the Wireless Service tab to view the WLAN services bound to the radio.
