HP MSR SERIES User Manual

258
Figure 260 Creating an SNMP group
2. Configure the SNMP group, as shown in Table 125.
Table 125 Configuration items
Item Descri
p
tion
Group Name Set the SNMP group name.
Security Level
Select the security level for the SNMP group. The available security levels are:
• NoAuth/NoPriv—No authentication no privacy.
• Auth/NoPriv—Authentication without privacy.
• Auth/Priv—Authentication and privacy.
IMPORTANT:
The security level for an existing SNMP group cannot be modified.
Read View Select the read view of the SNMP group.
Write View
Select the write view of the SNMP group.
If no write view is configured, the NMS cannot perform the write operations to all
MIB objects on the device.
Notify View
Select the notify view (the view that can send trap messages) of the SNMP group.
If no notify view is configured, the agent does not send traps to the NMS.
ACL
Associate a basic ACL with the group to restrict the source IP address of SNMP
packets. To restrict the intercommunication between the NMS and the agent, you
can allow or prohibit SNMP packets with a specific source IP address.
Configuring an SNMP user
Select Advanced > SNMP from the navigation tree, and then click the User tab to enter the page as
shown in Figure 261.
