HP MSR SERIES User Manual

173
Table 96 Configuration items
Item Descri
p
tion
Application Name Specify the name for the custom application.
Protocol
Specify the protocol to be used for transferring packets, including TCP, UDP, and All.
All means all IP carried protocols.
IP Address Specify the IP address of the server of the applications to be controlled.
Port
Match Rule
Specify the port numbers of the applications to be controlled.
When you select TCP or UDP for the Protocol parameter, the port configuration is
available:
• If you do not want to limit port numbers, do not select any option for the match rule.
In this case, you do not need to enter the start port and end port.
• If you want to limit a range of ports, select Range for the match rule, and then enter
the start port and end port to specify the port range.
• If you select other options of the match rule, you just need to enter the start port.
Start Port
End Port
Enabling application control
Select Security Setup > Application Control from the navigation tree and the page of the Application
Control tab is displayed by default, as shown in Figure 177. S
elect the applications and protocols to be
controlled from the Loaded Applications, Predefined Applications, and Custom Applications areas as
needed, and then click Apply.
Figure 177 Application Control
