HP MSR SERIES User Manual

229
Item Descri
p
tion
Check Logging
Select this box to keep a log of matched IPv4 packets.
A log entry contains the ACL rule number, action on the matched packets, protocol
that IP carries, source/destination address, source/destination port number, and
number of matched packets.
Source IP Address
Select the Source IP Address box, and enter a source IPv4 address and source
wildcard, in dotted decimal notation.
Source Wildcard
Time Range
Select the time range during which the rule takes effect.
The time ranges available for selection must have been created at the CLI on the
router.
Configuring a rule for an advanced IPv4 ACL
Select Advanced > QoS Setup > ACL IPv4 from the navigation tree and then select the Advanced Config
tab to enter the rule configuration page for an advanced IPv4 ACL.
