70 English
1 Air recirculation lever
2 Ventilation nozzles
Pull the air recirculation lever forwards.
ATTENTION
Only use this function for a limited period, since air is not ex-
changed from the outside with this setting.
Waste container controls
The switch for emptying the waste container is located next to the
driver's seat.
1 Switch the waste container high-pressure cleaner on and off
2 Additional socket-outlet, 12 V
3 Raise the waste container/attachment frame
4 Lower the waste container/attachment frame
Spray controls
1 Left side brush spray dosage knob
2 Right side brush spray dosage knob
3 Suction mouth spray dosage knob
1. Switch on the water pump (control panel).
2. Turn the corresponding dosage knob.
Note
Turning to the left increases the spray water volume. Turning to
the right increases the spray water volume.
Switch panel
1 Warning flasher system switch
2 Lighting switch
Position 0: Driving light off (pressed down)
Position 1: Parking light on (middle position)
Position 2: Driving light on (pressed up)
3 Working light switch
4 Rear fog lamp switch (option)
5 Front working light switch
6 Flashing beacon switch
7 Switch for heatable outside mirror (option)
The heating switches off again automatically
8 Heated windscreen switch
The heating switches off again automatically
9 Seat heater switch
Note
The indicator in the switch lights up when it is switched on.
Ignition lock
1 Engine off
2 Ignition on
3 Preheating (automatic)
4 Start the engine
The ignition lock is located below the travel direction lever.
