9
Troubleshooting
9-16 bizhub C250P (Phase 3)
To clear a paper misfeed in the fusing unit
1 Pull up the upper right-side door
release lever, and then open the
upper right-side door.
2 Push up the fusing unit cover, and
then pull out any misfed paper.
3 Push up the M2 release levers.
– Since the M2 release levers may
be difficult to move, push them
up forcefully one at a time.
– Do not manually return the M2
release levers to their original
positions. They will return to their
original positions when the fusing
unit cover is closed.
– When returning the M2 release
levers to their original positions, do not move them with your hand.
4 Pull out any misfed paper.
M2
M2
To Next Page
