Lantronix SGX 5150 User Manual

9: Administration
SGX 5150 IoT Device Gateway User Guide 103
TM
Using the CLI
 To enter the command level: enable > config > smtp
Using XML
 Include in your file: <configgroup name=”smtp”>
SNMP Settings
Simple Network Management Protocol (SNMP) settings may be viewed and configured in this
section.
Table 9-35 SNMP Settings
SNMP Settings Description
SNMP Agent
State Select to enable or disable the SNMP agent state.
Port Set the port of the SNMP agent.
Version Select the SNMP version used by the SNMP agent.
Read Community Specify the read community used by the agent (defaults to public community).
Write Community Specify the write community used by the agent (defaults to private community).
System MIB
System Contact Specify the system contact.
System Name Update the system name, as necessary. The default system name is .
System Description Update the system description, as necessary. The default system information
includes the manufacturer name, model name, version and the serial number of the
SGX 5150 gateway.
System Location Specify a system location for the SNMP setting.
MIB
Lantronix MIB File Click the Lantronix MIB file name to save and load it into the MIB browser and trap
receiver. This is the base MIB file for Lantronix products. Load or compile this file
first.
MIB File Click the MIB file name to save and load it into the MIB browser and trap receiver.
This is the product specific MIB file. Load or compile this after the Lantronix MIB
File.
SNMP Traps
Primary Destination Enter the Primary Destination.
Note: SNMP Traps fields become available when SNMP Agent State is enabled.
Primary Destination
Port
Enter the Primary Destination port.
Note: SNMP Traps fields become available when SNMP Agent State is enabled.
Secondary
Destination
Enter the Secondary Destination.
Note: SNMP Traps fields become available when SNMP Agent State is enabled.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
