8: Diagnostics
SGX 5150 IoT Device Gateway User Guide 73
Log
Configure a line or disable the diagnostic log on this Web Manager page.
Table 8-2 Log Settings
To Configure the Diagnostic Log Output
Using Web Manager
To configure the Diagnostic Log output, on the Diagnostics page, click Log.
Using the CLI
To enter the command level: enable > config > diagnostics > log
Using XML
Include in your file: <configgroup name=”diagnostics”>
Memory
The memory information includes the total, used, and available memory (in kilobytes).
To View Memory Usage
Using Web Manager
To view memory information, on the Diagnostics page, click Memory.
Using the CLI
To enter the command level: enable > device, show memory
Using XML
Include in your file: <statusgroup name="memory">
Ping
You can use Ping to test connectivity to a remote host.
Table 8-3 Ping Configuration
Diagnostics Log Description
Output Select a diagnostic log output type:
Disable - Turn off the logging feature.
Line 1 - Directs logging to the selected serial line.
USB 1 - Directs logging to the usb port.
IP Socket Description
Host Enter the IP address or host name for the SGX 5150 unit that you want to ping.
