SGX 5150 IoT Device Gateway User Guide 32
TM
4: Using DeviceInstaller
This chapter covers the steps for getting the SGX 5150 unit online and for viewing its current
configuration though the Lantronix DeviceInstaller application. DeviceInstaller is a free utility
program that discovers, configures, upgrades, and manages Lantronix devices. It can be
downloaded from the Lantronix website at www.lantronix.com/support/downloads
.
For instructions on using DeviceInstaller to configure the IP address and related settings or for
more advanced features, see the DeviceInstaller Online Help.
Note: Auto IP generates a random IP address in the range of 169.254.0.1 to
169.254.255.254, with a netmask of 255.255.0.0, if no BOOTP or DHCP server is found.
These addresses are not routable.
Installing DeviceInstaller
1. Download the latest version of Lantronix DeviceInstaller application from:
www.lantronix.com/support/downloads
.
2. Run the executable to start the installation process.
3. Respond to the installation wizard prompts. (If prompted to select an installation type, select
Typical.)
Accessing the SGX 5150 Using DeviceInstaller
Note: Make note of the MAC address on your SGX 5150 unit. It may be needed to
perform various functions in the DeviceInstaller application.
1. Click StartAll Programs  Lantronix DeviceInstaller 4.4  DeviceInstaller.
2. When DeviceInstaller starts, it will perform a network device search. To perform another
search, click Search.
3. Expand the SGX folder by clicking the + symbol next to the folder icon. A list of available
Lantronix SGX 5150 units appears.
4. Select a SGX 5150 unit by expanding its entry and clicking on its IP address to view its
configuration.
5. On the right page, click the Device Info tab. The current SGX 5150 configuration appears.
This is only a subset of the full configuration; the full configuration may be accessed via Web
Manager, CLI, or XML.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
