Lantronix SGX 5150 User Manual

9: Administration
SGX 5150 IoT Device Gateway User Guide 109
TM
Table 9-41 SSL Credential - Upload Certificate
Table 9-42 SSL Credential - Create New Self-Signed Certificate
To Configure an SSL Credential to Use an Uploaded Certificate
1. In the Web Manager, click the Administration tab.
2. Click SSL.
3. Click Credentials.
4. Under the View or Edit heading, click the credential that you want to modify to access the
information page for that credential.
5. To upload a New Certificate to assign to the credential, click Browse... beside New
Certificate, locate the valid certificate, then double-click the file to select it.
Upload Certificate
Settings
Description
New Certificate Click the Choose File... button to browse to the SSL certificate to be uploaded.
RSA or DSA certificates are allowed.
New Certificate Type Select the certificate type to upload:
 PEM
 PKCS7
 PKCS12
New Private Key Click the Choose File... button to browse to the SSL private key to be uploaded.
The key must belong to the entered certificate.
New Key Type Select the key type being uploaded:
 PEM
 Encrypted PEM
 PKCS12
Submit (button) Click the Submit button to enter the settings. The Submit button appears when
new settings are entered.
Field Description
Country (2 Letter code) Enter the 2 letter code for the country where the organization is located. This is a
two-letter ISO code (e.g., “US” for the United States).
State/Province Enter the state or province where the organization is located.
Locality (City) Enter the city where the organization is located.
Organization Enter the organization name to which the SGX 5150 unit belongs.
Organization Unit Enter the organization unit which specifies the department or organization to
which the SGX 5150 unit belongs.
Common Name Enter a network name for the SGX 5150 unit when installed in the user’s network
(usually the fully qualified domain name). It is identical to the name that is used to
access the SGX 5150 unit with a web browser without the prefix
http://. In
case the name given here and the actual network name differ, the browser will
pop up a security warning when the SGX 5150 unit is accessed using HTTPS.
Expires Type the date that the self-signed certificate expires in mm/dd/yyyy format.
Type Select RSA or DSA.
Key length Select the key length from the drop-down menu.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
