Lantronix SGX 5150 User Manual

9: Administration
SGX 5150 IoT Device Gateway User Guide 86
TM
Using the CLI
 To enter the gateway command level: enable > config > gateway
Using XML
 Include in your file: <configgroup name="ga teway"> <configitem name="wan">
Port Forwarding
Port forwarding allows remote computers (for example, computers on the Internet) to connect to a
specific computer or service within a private local-area network (LAN). Port Forwarding rules
apply to inbound traffic and will not work if the SGX 5150 gateway is not reachable or traffic to
certain ports is blocked before it reaches the gateway.
If traffic is going through firewalls, all referenced ports on the gateway and LAN devices must be
accessible.
Table 9-10 Port Forwarding Rules List
Table 9-11 Adding a New Port Forwarding Rule
Port Forwarding Rule Description
Enabled Enables the port forwarding rule.
Delete Deletes the port forwarding rule.
Name User friendly name for the rule. Click on the [Edit] icon to make changes.
Ingress IP Address: Port
Range
Port or Port range for the rule.
Protocol Protocols for the rule: TCP, UDP, or Both.
IP Address: Target Port Target for the port forwarding rule.
Adding New Port
Forwarding Rule
Settings
Description
Name Enter a User Friendly name for the rule (optional)
Ingress IP Address
(Optional)
Enter the destination address of the packets. This option can only be used with
single ports and not with port range.
Start Port Enter the starting port number.
End Port Enter the end port number (optional). If start port and end port are same it
assumes a single port. If start port and end port are not the same – it is a port
range.
Protocol Select the protocol for the rule. TCP, UDP, or Both.
IP Address Enter the target for the port forwarding rule.
Target Port Indicate the target port. This is the port which the packets are to be forwarded.
This options can only be used with single ports and not with port range. If this
value is not specified. If this value is not specified, the packets are forwarded to
same port or pot range. Optional field.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
