SGX 5150 IoT Device Gateway User Guide 69
7: Filesystem
The Filesystem page provides statistics and current usage information for the flash filesystem.
From here you may format the entire filesystem.
Directories can be created, deleted, moved, and renamed. A directory must be empty before it
can be deleted.
Files can be created, deleted, moved, renamed, uploaded via HTTP, and transfered to and
from a TFTP server. Newly created files will be empty.
Some filesystems may contain a 'lost+found' directory.
Table 7-1 File Modification Settings
File Transfer and Modification
Files can be transferred to and from the SGX 5150 device via the TFTP protocol. This can be
useful for saving and restoring XML configuration files. Files can also be uploaded via HTTP.
Table 7-2 File Transfer Settings
File Modification
Commands
Description
rm
Removes the specified file from the file system.
touch
Creates the specified file as an empty file.
cp
Creates a copy of a file.
mkdir
Creates a directory on the file system.
rmdir
Removes a directory from the file system.
format
Format the file system and remove all data.
File Transfer Settings Description
Create Type in a File or Directory name and click the Create button. The newly created
File or Directory will appear above.
Upload File Click to Choose File to location of the file to be uploaded via HTTP. Click Upload
to upload the chosen file.
Copy File Enter the Source and Destination name for file to be copied and click the Copy
button.
Move Enter the Source and Destination name for file to be moved and click the Move
button.
TFTP
Action Select the action that is to be performed via TFTP:
Get = a “get” command will be executed to store a file locally.
Put = a “put” command will be executed to send a file to a remote location.
Local File Enter the name of the local file on which the specified “get” or “put” action is to be
performed.
