6: Network Settings
SGX 5150 IoT Device Gateway User Guide 64
Using the CLI
To enter the command level: enable > config > if 2 > link
Using XML
Not applicable.
To Show WPS Status
Using the CLI
To enter the command level: enable > config > if 2 > link
Using XML
Not applicable.
WLAN Scan/QuickConnect
Going to this page initiates a scan of wireless networks within range of the SGX 5150 unit and
allows users to add a WLAN profile after testing it. This list refreshes automatically every 15
seconds. There is also an option to automatically update the scan results every 60 seconds, which
is disabled by default. The scan results contain the following prepopulated information about each
wireless device: service set identifier (SSID), basic service set identifier (BSSI), channel number
(CH), received signal strength indication (RSSI), and Security Suite. You may also run a filtered
scan of network names by the first few letters within the name.
Click on any network name for QuickConnect configuration.
Table 6-20 WLAN Scan/Quick Connect Results
WLAN Quick Connect
Settings
Description
Network Name (search
field)
Enter the first few letters of a network name in the search field before pressing
the Scan button (next field description below).
Scan “<network SSID>” Click Scan to search for all network names containing the first few letters
entered in the Network Name search field. Performs a scan for devices within
range of the SGX 5150 unit. To limit the scan to devices that are configured with
the specified SSID, include the network SSID. To perform a scan for all devices,
omit the network SSID.
The command syntax requires the opening and closing quotation marks. If you
omit the SSID, include the quotation marks, for example, scan “”.
Refresh scan results
every 60 seconds
(check box)
To automatically update the list every 60 seconds, select the checkbox.
To stop automatically updating the list, clear the checkbox.
SSID To display a network configuration profile, click the service set identifier (SSID)
of a specific network.
BSSID The basic service set identifier (BSSID) is a unique 48-bit address that identifies
the access point that creates the wireless network.
CH (Channel) The channel number and frequency (MHz) of a network.
