Lantronix SGX 5150 User Manual

6: Network Settings
SGX 5150 IoT Device Gateway User Guide 60
TM
Using the CLI
 To enter the command level: enable > config > ip
Using XML
 Include in your file: <configgroup name=”ip”>
ICMP Settings
This page contains lower level ICMP Network Stack specific configuration items.
Table 6-16 ICMP Protocol Stack Settings
To Configure ICMP Protocol Stack Settings
Using Web Manager
 To configure ICMP protocol settings, on the Network page, click Protocol Stack > ICMP.
Using the CLI
 To enter the command level: enable > config > icmp
Using XML
 Include in your file: <configgroup name=”icmp”>
ARP Settings
This page contains lower level Address Resolution Protocol (ARP) network stack specific
configuration items.The ARP cache can be manipulated manually by adding new entries and
deleting existing ones. Added entries are static and for test purposes only.
Table 6-17 ARP Protocol Stack Settings
Protocol Stack ICMIP
Settings
Description
State The State selection is used to turn on/off processing of ICMP messages.
This includes both incoming and outgoing messages. Choose Enabled or
Disabled.
Protocol Stack ARP
Settings
Description
IP Address Enter the IP address to add the ARP cache.
MAC Address Enter the MAC address to add to the ARP cache.
Interface Select the type of interface if adding to the ARP cache.
Add (button) Click this button to add a new entry (after entering the IP address, MAC
address and Interface info for the new entry above.)
Clear Click the Clear link above all listed addresses to remove all the addresses.
Remove Click the Remove link beside a specific address to remove it.

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
