Lantronix SGX 5150 User Manual

9: Administration
SGX 5150 IoT Device Gateway User Guide 105
TM
Note: SSH Keys from other programs may be converted to the required SGX 5150
format. Use Open SSH to perform the conversion.
SSH Server: Authorized Users
The SSH Server Authorized Users are used by all applications that play the role of an SSH Server
during Tunneling in Accept Mode. Every user account must have a Password.
The user's Public Keys are optional and only necessary if public key authentication is wanted.
Using public key authentication will allow a connection to be made without the password being
asked at that time.
Note: When uploading the security keys, ensure the keys are not compromised in
transit.
Table 9-37 SSH Server Authorized Users
SSH Client: Known Hosts
The SSH Client Known Hosts are used by all applications that play the role of an SSH Client.
Specifically in Connect Mode. Configuring these public keys are optional, but if they exist another
layer of security is offered which helps prevent Man-in-the-Middle (MITM) attacks.
Public Key Click the Choose File... button to navigate to the existing public key you want to
upload. In Web Manager, you can also browse to the public key to be uploaded.
Submit (button) Click the Submit button after changes are made in the above Upload Keys fields.
Key Type Select a key type to use for the new key:
 RSA
 DSA
Bit Size
Select a bit length for the new key:
 512
 768
 1024
 2048
 4096
Submit (button) Click the Submit button after changes are made in the above Create New Keys
fields.
SSH Settings Description
Username Enter a new username or edit an existing one.
Password Enter a new password or edit an existing one.
Public RSA Key Click the Browse... button to browse to the existing public RSA key you want to use
with this user. In Web Manager, you can also browse to the public RSA key to be
uploaded. If authentication is successful with the key, no password is required.
Public DSA Key Click the Browse... button to browse to the existing public DSA key you want to use
with this user. In Web Manager, you can also browse to the public DSA key to be
uploaded.If authentication is successful with the key, no password is required.
Add/Edit (button) Click the Add/Edit button after changes are made in the above SSH Server:
Authorized Users fields.
SSH Settings Description

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
