Lantronix SGX 5150 User Manual

6: Network Settings
SGX 5150 IoT Device Gateway User Guide 59
TM
To View and Configure Wired (USB0) Network Failover Settings
Using Web Manager
 To view USB Failover statistics, click Network on the menu and select Wired Network (USB)
> Failover.
 To modify USB Failover settings, click Network on the menu and select Wired Network
(USB) > Failover > Configuration.
Using the CLI
 To enter the usb0 link command level: enable > config > if 3 > failover
Using XML
 Include in your file: <configgroup name="network failover" instance="usb0">
Protocol Stack
There are various low level network stack specific items that are available for configuration. This
includes settings related to IP, ICMP, and ARP, which are described in the sections below.
IP Settings
This page contains lower level IP Network Stack specific configuration items.
Table 6-15 IP Protocol Stack Settings
To Configure IP Protocol Stack Settings
Using Web Manager
 To configure IP protocol settings, on the Network page, click Protocol Stack > IP.
Interval Indicate the interval in which to test reachability
Failover Threshold Indicate the allowed number of failed pings – after which the SGX 5150 gateway
will failover to the wlan0 interface.
Failback Threshold Indicate the number of successful pings – after which the SGX 5150 gateway will
failback to the Ethernet interface.
Protocol Stack IP Settings Description
IP Time to Live Enter the number of hops to be transmitted before the packet is discarded.
This value typically fills the time to live in the IP header. SNMP refers to this
value as "ipDefaultTTL".
Multicast Time to Live This value fills the Time To Live in any multicast IP header. Normally this
value will be one so the packet will be blocked at the first router. It is the
number of hops allowed before a multicast packet is discarded. Enter the
value to be greater than one to intentionally propagate multicast packets to
additional routers.
Wired (usb0) Network
(Failover) Settings
Description

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
