Lantronix SGX 5150 User Manual

6: Network Settings
SGX 5150 IoT Device Gateway User Guide 46
TM
To Configure Network Interface Settings
Using Web Manager
 To view Ethernet (eth0) Interface statistics, on the Network page, select Wired Network >
Interface.
 To configure Ethernet (eth0) interface settings, on the Network page, select Wired Network >
Interface > Configuration.
Using the CLI
 To enter the command level: enable > config > if 1
Primary DNS Enter the IP address of the primary domain name server (DNS.)
Note: This setting will be used when either Static IP or Auto IP is active, or if
DHCP/BOOTP is active and no DNS server was acquired from the server.
Secondary DNS Enter the IP address of the secondary domain name server.
Note: This setting will be used when either Static IP or Auto IP is active, or if
DHCP/BOOTP is active and no DNS server was acquired from the server.
IPv6 State Select to enable or disable.
IPv6 DHCP Client Select to turn On or Off. At bootup, after the physical link is up, the SGX 5150 unit
will attempt to obtain IPv6 settings from a DHCPv6 server and will periodically
renew these settings with the server.
 On: enables the SGX 5150 server to obtain IPv6 setting from a DHCPv6 server
upon bootup.
 Off: enables the SGX 5150 server to obtain IPv4 settings from a DHCP server
upon bootup.
Note: Overrides the configured IP address/mask, gateway, hostname, and
domain. Changing this value requires you to reboot the SGX 5150 gateway. Within
Web Manager, click Renew to renew the DHCPV6 lease.
IPv6 Auto
Configuration
Select to turn On or Off IPv6 auto configuration.
IPv6 IP Address Enter the static IPv6 address to use for the interface.
Note: This setting is used if Static IPv6 is active (DHCPv6 is Disabled). Changing
this value requires a reboot. When DHCPv6 is enabled, the SGX 5150 unit tries to
obtain an IPv6 address from a DHCPv6 server. If it cannot, then SGX 5150 unit
generates and uses a Link local IPv6 address.
IPv6 Default Gateway Enter the default IPv6 default gateway.
IPv6 Domain Enter the domain name suffix for the interface.
Note: This setting will be used when either Static IP or Auto IP is active, or if
DHCP/BOOTP is active and no Domain Suffix was acquired from the server.
IPv6 Primary DNS Enter the IP address of the primary domain name server.
Note: This setting will be used when either Static IP or Auto IP is active, or if
DHCP/BOOTP is active and no DNS server was acquired from the server.
IPv6 Secondary DNS Enter the IP address of the secondary domain name server.
Note: This setting will be used when either Static IP or Auto IP is active, or if
DHCP/BOOTP is active and no DNS server was acquired from the server.
Field/Button Description

Lantronix SGX 5150 Specifications

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
