8: Device Ports
SLC™ Console Manager User Guide 104
4. Click the Apply button.
5. To view the status detected by the Sensorsoft, click the Sensorsoft Status link to the right of
the table.
Device Port Commands
The following CLI commands correspond to the web page entries described above.
To configure a single port or a group of ports (for example, set deviceport port 2-5,6,12,15-
16 baud 2400):
set deviceport port <Device Port List or Name> <one or more device port
parameters>
Parameters:
auth <pap|chap>
banner <Banner Text>
baud <300-115200>
breakseq <1-10 Chars>
calleridcmd <Modem Command String>
calleridlogging <enable|disable>
chapauth <chaphost|localusers>
chaphost <CHAP Host or User Name>
chapsecret <CHAP Secret or User Password>
The user defines the secret.
checkdsr <enable|disable>
closedsr <enable|disable>
databits <7|8>
device <none|slp8|slp16|slp8exp8|slp8exp16|slp16exp8|
slp16exp16|sensorsoft|servertech>
dialbackretries <1-10>
dialbackdelay <PPP Dial-back Delay>
dialinlist <Host List for Dial-in>
dialoutnumber <Phone Number>
dialoutlogin <User Login>
dialoutpassword <Password>
dialbacknumber <usernumber|Phone Number>
dodauth <pap|chap>
dodchaphost <CHAP Host or User Name>
dodchapsecret <CHAP Secret or User Password>
flowcontrol <none|xon/xoff|rts/cts>
group <Local or Remote Group Name>
idletimeout <disable|1-9999 seconds>
ipaddr <IP Address>
initscript <Initialization Script>
Low Humidity Enter the relative humidity permitted on the device the sensor is monitoring below
which the sensor sends a trap to the SLC console manager.
High Humidity Enter the highest relative acceptable humidity permitted on the device above which
the sensor sends a trap to the SLC unit.
Traps Select to indicate the SLC device should send a trap or configured Event Alert
when the sensor detects an out-of-range configured threshold.

Lantronix SLC8 Specifications

General

Brand	Lantronix
Model	SLC8
Category	Server
Language	English
