9: PC Cards
SLC™ Console Manager User Guide 141
Figure 9-2 PC Card - Storage Page
4. Enter the following fields.
5. Click the Apply button.
Slot
(view only)
Slot on the SLC console manager where the PC Card is inserted.
Device (view only) Type of PC Card (modem or storage).
Type (view only) Information read from PC Card.
State (view only) Applies to storage cards.
Mount Click the checkbox to mount the first partition of the Compact Flash on the SLC
device (if not currently mounted). Once mounted, a Compact Flash is used for
device port logging and saving/restoring configurations.
Unmount Click the checkbox to eject the compact flash from the SLC console manager after
unmounting it.
Warning: If you eject a Compact Flash from the SLC device without
unmounting it, subsequent mounts of a PC Card Compact Flash in either
slot may fail, and you will need to reboot the SLC console manager to
restore PC Card functionality.
Format Select to unmount the Compact Flash (if it is mounted), remove all existing
partitions, create one partition on the Compact Flash, format it with the selected file
system (ext2 or FAT), and mount it.
Filesystem Select ext2 or FAT, the file systems the SLC console manager supports.
