10: USB Port
SLC™ Console Manager User Guide 152
Text Mode
Use Sites Enables the use of site-oriented modem parameters which can be activated by
various modem-related events (authentication, outbound network traffic for dial-
on-demand connections, etc.). Sites can be used with the following modem
states: dial-in, dial-back, dial-on-demand, dial-in & dial-on-demand, dial-back &
dial-on-demand, and CBCP server.
Group Access If undefined, any group can access the modem (text login only). If one or more
groups are specified (groups are delimited by the characters ' ' (space), ','
(comma), or ';' (semicolon)), then any user who logs into the modem must be a
member of one of the specified groups, otherwise access will be denied. Users
authenticated via RADIUS may have a group (or groups) provided by the
RADIUS server via the Filter-Id attribute that overrides the group defined for a
user on the SLC console manager. A group provided by a remote server must be
either a single group or multiple groups delimited by the characters ' ' (space), ','
(comma), ';' (semicolon), or '=' (equals) - for example "group=group1,group2;" or
"group1,group2,group3".
Initialization Script Commands sent to configure the modem may have up to 100 characters. Consult
your modem’s documentation for recommended initialization options. If you do
not specify an initialization script, the SLC unit uses a default initialization string of
AT S7=45 SO=0 L1 V1 X4 &D2 &c1 E1 Q0.
Note: We recommend that the modem initialization script always be preceded
with AT and include E1 V1 x4 Q0 so that the SLC device may properly control
the modem.
Modem Timeout Timeout for all modem connections. Select Yes (default) for the SLC console
manager to terminate the connection if no traffic is received during the configured
idle time. Enter a value of from 1 to 9999 seconds. The default is 30 seconds.
Caller ID Logging Select to enable the SLC unit to log caller IDs on incoming calls. Disabled by
default.
Note: For the Caller ID AT command, refer to the modem user guide.
Modem Command
Modem
AT command used to initiate caller ID logging by the modem.
Note: For the
AT command, refer to the modem user guide.
Dial-back Number Users with dial-back access can dial into the SLC console manager and enter
their login and password. Once the SLC unit authenticates them, the modem
hangs up and dials them back.
Select the phone number the modem dials back on -a fixed number or a number
associated with their login. If you select Fixed Number, enter the number (in the
format 2123456789).
The dial-back number is also used for CBCP client as the number for a user-
defined number. See Device Ports - Settings (on page 94) for more information.
Dial-back Delay For dial-back and CBCP Server, the number of seconds between the dial-in and
dial-out portions of the dialing sequence.
Dial-back Retries For dial-back and CBCP Server, the number of times the SLC or SLB unit will
retry the dial-out portion of the dialing sequence if the first attempt to dial-out fails.
Timeout Logins If you selected Text mode, you can enable logins to time out after the connection is
inactive for a specified number of minutes. The default is No. This setting is only
applicable for text mode connections. PPP mode connections stay connected until
either side drops the connection. Disabled by default.
