11: Connections
SLC™ Console Manager User Guide 161
Figure 11-6 Devices > Connections
2. For a device port, enter the following:
Outgoing
Connection
Timeout
Select to turn on or turn off the connection timeout:
No for no timeout
Yes for a timeout. Specify the number of seconds in the seconds field.
Port The number of the device port you are connecting.
This device port must be connected to an external serial device and must not have
command line interface logins enabled, be connected to a modem, or be running a
loopback test.
Note: To see the current settings for this device port, click the Settings link.
Data Flow Select the arrow showing the direction (bidirectional or unidirectional) the data will flow in
relationship to the device port you are connecting.
