8: Device Ports
SLC™ Console Manager User Guide 110
Figure 8-8 Devices > Device Ports - Logging
2. Enter the following:
Local Logging
Email/SNMP Traps
Local Logging If you enable local logging, each device port stores 256 Kbytes (approximately 400
screens) of I/O data in a true FIFO buffer. Disabled by default.
Clear Local Log Select the checkbox to clear the local log.
View Local Log Click this link to see the local log in text format.
Email/Traps Select the checkbox to enable email and SNMP logging. Email logging sends an
email message to pre-defined email addresses or an SNMP trap to the
designated NMS (see Chapter 7: Services on page 68) when alert criteria are
met. Disabled by default.
Send If you enabled email and SNMP logging, select what type of notification log to
send:
Email (default)
SNMP Trap
Both
