6: Basic Parameters

SLC™ Console Manager User Guide 64

2. Enter the following:

Dynamic Routing

Static Routing

3. Click the Apply button.

Note: To display the routing table, status or specific report, see the section,

Status/Reports on page 234.

Equivalent Routing Commands

The following CLI commands correspond to the web page entries described above.

To configure static or dynamic routing:

set routing [parameters]

Parameters:

rip <enable|disable>

route <1-64> ipaddr <IP Address> mask <Netmask> gateway <IP Address>

static <enable|disable>

version <1|2|both>

Note: To delete a static route, set the IP address, mask, and gateway parameters to

0.0.0.0.

To set the routing table to display IP addresses (disable) or the corresponding host names

(enable):

show routing [resolveip <enable|disable>] [email <Email Address>]

Note: You can optionally email the displayed information.

Enable RIP Select to enable Dynamic Routing Information Protocol (RIP) to assign routes

automatically. Disabled by default.

RIP Version Select the RIP version. The default is 2.

Enable Static

Routing

Select to assign the routes manually. The system administrator usually provides the

routes. Disabled by default.

 To add a static route, enter the IP Address, Subnet Mask, and Gateway for the

route and click the Add/Edit Route button. The route displays in the Static Routes

table. You can add up to 64 static routes.

 To edit a static route, select the radio button to the right of the route, change the IP

Address, Subnet Mask, and Gateway fields as desired, and click the Add/Edit

Route button.

 To delete a static route, select the radio button to the right of the route and click the

Delete Route button.
