IMPORTANT: The sterndrive is not shifting properly if the sterndrive shifts after the engine throttle is advanced.
5. Move the remote control handle to the forward, idle speed position.
6. Check that the sterndrive propeller shaft is turning in the forward direction.
7. Shift the remote control handle to the neutral, idle speed position.
8. Check that the sterndrive propeller shaft is not turning.
9. Shift the remote control handle to the reverse, idle speed position.
10. Check that the sterndrive propeller shaft is turning in the reverse direction.
11. If the sterndrive will not shift:
a. Remove the sterndrive and check the shift linkage assembly and shift cable.
b. Check the shift cable installation and adjustment. Refer to the Bravo sterndrive service manual for detailed
instructions.
IMPORTANT: Be sure that the shift cables are routed in such a way as to avoid sharp bends and contact with moving
parts. Do not fasten any items to the shift cables.
Engine Installation and Initial Engine Alignment—TowSport, Inboard
Engine Mount Preadjustment
1. Remove the two engine covers shown in the following:
a. Pull the outside engine cover up to remove it from the four rubber mount grommets.
b. Lift up on the front of the second cover to disengage the cover from the front grommets. Pull the cover toward the
front of the vessel to remove it from the two rear grommets.
a - Front grommets
b - Rear grommets
Installation
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 2B-27
