Mercury MERCRUISER Service Manual

2. Remove the coupler or drive plate.
a - Bravo coupler
b - HD Bravo coupler
c - Driveshaft extension coupler
3. Remove the flywheel.
a - Flywheel
b - Screws (6)
Oil Pan
Removal
!
WARNING
Fuel is flammable and explosive. Ensure that the key switch is off and the lanyard is positioned so that the engine cannot
start. Do not smoke or allow sources of spark or open flame in the area while servicing. Keep the work area well ventilated
and avoid prolonged exposure to vapors. Always check for leaks before attempting to start the engine, and wipe up any
spilled fuel immediately.
1. Drain the engine oil from the oil pan.
a
c
b
59617
b
a
59619
Engine Disassembly
Page 3A-28 © 2016 Mercury Marine 90-8M0099748 eng DECEMBER 2015
