Wire Color Code Abbreviations
Wire Color Abbreviations
BLK Black
BLU Blue
BRN Brown GRY Gray
GRN Green ORN or ORG Orange
PNK Pink PPL or PUR Purple
RED Red TAN Tan
WHT White YEL Yellow
LT or LIT Light DK or DRK Dark
Starter Specifications
The permanent‑magnet gear‑reduction starter motor features small permanent magnets mounted inside its field frame. These
magnets take the place of current‑carrying field coils mounted on iron pole pieces. A 4:1 ratio internal gear reduction results in
armature speeds in the 7000 RPM range. The armature and driveshaft are mounted on roller or ball bearings in the place of
bushings. The solenoid switch, plunger, return spring, and shift lever are permanently mounted in the drive housing.
Delco Starter Specifications
Model
Delco
ID Number
Engine
Rotation
Voltage
No Load Test
Minimum Current Draw Maximum Current Draw Minimum RPM Maximum RPM
PG260G 8000669 LH 12.0 V 35 A 85 A 2550 4150
Starting System
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 4A-3
