Remove the flange screw.
a - Flange screw
b - Oil pump drive
Flywheel and Housing
Flywheel Housing Removal
1. Remove the flywheel housing cover.
a - Flywheel housing cover
b - Screws (2)
c - Flywheel housing
2. Remove the ground wires from the flywheel housing.
IMPORTANT: The flywheel housing bolts must be installed in the same location as removed.
3. Remove the screws and studs from the flywheel housing.
4. Remove the flywheel housing.
Flywheel Removal
1. Remove the flywheel housing.
Engine Disassembly
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 3A-27
