Description Nm lb‑in. lb‑ft
Propeller shaft coupler to transmission output flange bolt 68 – 50.2
IMPORTANT: Be certain to tighten the trunnion clamping fasteners on the engine mounts that were loosened during
removal.
16. Tighten the trunnion clamping fasteners on the engine mounts that were loosened during removal to the specified torque.
Description Nm lb‑in. lb‑ft
Trunnion clamping fasteners on the engine mounts 68 – 50.2
17.
Refill the transmission with the specified fluid. Refer to Filling.
18.
Connect and adjust the shift cables. Refer to Shift Cable Installation and Adjustment.
19. Connect the battery cables. Be certain to connect the negative (–) cable last.
20. Check for leaks and check the fluid level after the first engine start‑up.
Shift Cable Installation and Adjustment
Shift Cable Installation
45C
ZF/45C, 45IV, 63A, 65IV Transmissions
Page 9A-16 © 2016 Mercury Marine 90-8M0099748 eng DECEMBER 2015
