2. Measure the valve spring for squareness.
3. Replace the valve spring if not square.
4. Use a spring compressor to measure the valve spring tension. Replace the spring if the measured value is less than the
specified limit.
a - Valve spring compressor
b - Torque wrench
Description Part Number
Valve spring compressor J9666
Description 6.2 Liter (377 cid)
Pressure
Valve closed 350 N (78.68 lb) at 46.19 mm (1.818 in.)
Valve open 1084 N (243.69 lb) at 32.3 mm (1.2717 in.)
Repair
Valve Reconditioning
1. Recondition the valve face to the proper angle if the valve face is pitted or worn.
2. Measure the valve margin. If the valve margin is less than the specified amount after reconditioning, replace the valve.
Engine Inspection and Assembly
90-8M0099748 eng DECEMBER 2015 © 2016 Mercury Marine Page 3B-47
