Passport 12/Passport 8 Operator’s Manual 8-21
Advanced ECG algorithm
Arrh. event Range Default Step Unit
PVCs High 1 to 100 10 1 /min
Asys. Delay 3 to 10 5 1 s
Tachy High 60 to 300
Adult: 120
Pediatric: 160
5 bpm
Brady Low 15 to 120
Adult: 50
Pediatric: 75
5 bpm
Extreme Tachy 120 to 300
Adult: 160
Pediatric: 180
5 bpm
Extreme Brady 15 to 60
Adult: 35
Pediatric: 50
5 bpm
Multif. PVC's Window 3 to 31 15 1 /min
Vtac Rate 100 to 200 Adult, pediatric: 130 5 bpm
Vtac PVCs 3 to 99 6 1 /min
Pause Time 1.5, 2.0,2.5 2 / s
Vbrd PVCs 3 to 99 5 1 /min
Vbrd Rate 15 to 60 40 5 bpm
8.8.4 Setting the Extended Arrhythmia (For Advanced ECG Algorithm Only)
The following arrhythmia events are defined as extended arrhythmia:
 Extreme Tachy
 Extreme Brady
 Vent. Brady
 Nonsus. Vtac
 Multif. PVC
 Irr. Rhythm
 Pause
 Afib
You can select [Main Menu]→[Maintenance >>]→[User Maintenance >>]→enter the required password→select
[Alarm Setup >>], and set [Extended Arrh.] to [Enable] or [Disable]. When [Extended Arrh.] is set to [Disable], the
monitor does not analyze the extended arrhythmia events, and corresponding alarms are not given.
8.8.5 Reviewing Arrhythmia Events
Please refer to section 19.4 Reviewing Events.
