Passport 12/Passport 8 Operator’s Manual 16-7
WARNING
Please consider the patient’s actual bearing capability and select the appropriate flow rate when setting the
flow rate.
16.4.9 Setting up the CO
2
Wave
Select the CO
2
parameter window to access the [CO2 Setup] menu, in which you can:
Select [Wave Type] and then select [Draw] or [Fill]:
[Draw]: The CO
2
wave is displayed as a curved line.
[Fill]: The CO
2
wave is displayed as a filled area.
Select [Sweep], and then select the appropriate setting. The faster the wave sweeps, the wider the wave is.
Change the size of the CO
2
waveform by adjusting the wave [Scale].
16.5 Setting RR Source
To set RR source:
1. Select the CO
2
parameter window to access the [CO2 Setup] menu.
2. Select [RR Source] and then select a source or [Auto] from the dropdown list.
The [RR Source] setting takes effect simultaneously to the Resp, CO
2
, and AG modules. For details, please refer to section
9.9 Setting Respiration Rate Source.
16.6 Barometric Pressure Compensation
Both sidestream and microstream CO
2
modules have the function of automatic barometric pressure compensation (the
system automatically measures the barometric pressure which the monitor is exposed to).
