Passport 12/Passport 8 Operator’s Manual 26-5
26.7 AG Tests
26.7.1 AG Leakage Test
Follow this procedure to perform the test:
1. Plug the AG module into the module rack.
2. Wait until the AG module warmup is finished, and then use your hand or other objects to completely block the gas
inlet of the AG module. An alarm message [AG Airway Occluded] will appear on the screen.
3. Block the gas inlet for 60 s. Select [Main menu]→[Maintenance >>]→[User Maintenance >>]→enter the required
password→[Calibrate AG >>], and check that current flow rate is less than 10ml/min.
If the flow rate is less than 10ml/min and the alarm message [AG Airway Occluded] does not disappear, it indicates that
the module does not leak.
If the alarm message does not appear, or the flow rate is greater than or equal to 10ml/min, it indicates that the module
leaks. If the problem remains, contact your service personnel for help.
26.8 Calibrating the Touchscreen
1. Select [Main Menu]→[Maintenance >>]→ [Cal. Touchscreen].
2.
will, in turn, appear at different positions of the screen. Select each as it appears on the screen.
3. After the calibration is completed, the message [Screen Calibration Completed!] is displayed. Select [Ok] to
confirm the completion of the calibration.
26.9 Entering/Exiting Demo Mode
To enter the Demo mode:
1. Select [Main Menu]→[Maintenance >>].
2. Select [Demo >>]. Enter the required password and then select [Ok].
To exit the Demo mode:
1. Select [Main Menu]→[Maintenance >>].
2. Select [Exit Demo] and then select [Ok].
3. The monitor exits the Demo mode.
WARNING
 The Demo mode is for demonstration purpose only. To avoid the potential risk of the simulated data being
mistaken for the monitored patient's data, do not enter the Demo mode while monitoring a patient.
Otherwise, improper patient monitoring and delayed treatment could occur.
