Mindray Passport 8 Operator's Manual

A-2 Passport 12/Passport 8 Operator’s Manual
AG module
Item Operating conditions Storage conditions
Temperature (°C) 10 to 40 -20 to 60
Relative humidity (noncondensing) 15% to 95% 10% to 95%
Barometric (kPa) 70 to 107.4 70 to 107.4
NOTE
 The environmental specifications of unspecified parameters are the same as those of the main unit of
Passport 12.
A.2 Power Supply Specifications
AC power
Line voltage
100 to 240 VAC (±10％)
Current 1.3 to 0.5 A
Frequency
50/60 Hz (±3Hz)
Battery
Battery Type Chargeable Lithium-Ion, 11.1DVC, 4.5 Ah
Run time
Passport 12
≥ 4 hours
when powered by one new fully-charged battery (25°C, SpO
2
, ECG, disconnected from
Temp cable, Auto NIBP measurements at intervals of 15 minutes)
≥ 8 hours
when powered by two new fully-charged batteries (25°C, SpO
2
sensor and ECG cable
connected, Temp cable not connected, Auto NIBP measurements at an interval of 15
minutes)
Passport 8
≥ 6 hours
when powered by a new fully-charged battery (25°C, SpO
2
sensor and ECG cable
connected, Temp cable not connected, Auto NIBP measurements at an interval of 15
minutes
Charge time
Less than 3 hours to 90%, and less than 4 hours to 100% when the monitor is off.
Less than 8 hours to 90%, and less than 12 hours to 100% when the monitor is on.
Shutdown delay at least 20 min (after a low battery alarm first occurs)
A.3 Physical Specifications
Model
Size (Width×Height×Thickness)
Weight Remark
Passport 12
318mm×274mm×128mm
(12.6 inch × 10.8 inch × 5.1 inch)
≤4.5 kg (10 pound)
Standard parameters,
including touchscreen and
recorder, and battery (2
batteries for Passport 12)
Passport 8
238mm×225mm×128mm
(9.4 inch × 8.9 inch × 5.1 inch)
≤3.5 kg (7.8 pound)
