Passport 12/Passport 8 Operator’s Manual 5-3
5.4 Setting Default Configuration
The monitor will load the pre-set default configuration in the following cases:
The monitor restarts after being switched off for more than 120 seconds.
A patient is admitted.
A patient is discharged.
Patient data is cleared.
Patient category is changed.
To set the default configuration:
1. Select [Select Default Config. >>] in the [Manage Configuration] menu.
2. In the [Select Default Config.] menu, select [Load the Latest Config.] or [Load Specified Config.].
When you select [Load Specified Config.], the restored configuration is subject to the patient category (adult, pediatric
or neonate). This configuration can be either factory configuration or a saved user configuration. As an example, select
[Default Adu Config.] and then select [Defaults] or user configuration(s).
When you select [Load the Latest Config], the latest configuration is loaded when the monitor is started or a patient is
admitted.
NOTE
To identify which configuration is restored when the monitor starts, enter the main screen to check the
prompt information at the lower part of the screen (displayed for about 10 seconds).
5.5 Saving Current Settings
Current settings can be saved as a user configuration. Up to 5 user configurations can be saved.
To save current settings:
1. Select [Save Current Settings As >>] in the [Manage Configuration] menu.
2. In the pop-up dialog box, enter the configuration name and then select [Ok]. The current settings are saved as a
user configuration with the name you entered.
