Passport 12/Passport 8 Operator’s Manual 21-3
21.4.3 Setting the Realtime Recording Length
After starting a realtime recording, the recording time depends on your monitor’s settings. In the [Record Setup] menu,
select [Length] and then select [8 s] or [Continuous].
[8 s]: record 4-second waveforms respectively before and after current moment.
[Continuous]: record the waveforms from the current moment until stopped manually.
21.4.4 Setting the Interval between Timed Recordings
Timed recordings start automatically at preset intervals. Each recording lasts 8 seconds. To set the interval between
timed recordings: in the [Record Setup] menu, select [Interval] and then select the appropriate setting.
21.4.5 Changing the Recording Speed
In the [Record Setup] menu, select [Paper Speed] and then select [25 mm/s] or [50 mm/s]. This setting is for all
recordings containing waveforms.
21.4.6 Clearing Recording Tasks
In the [Record Setup] menu, select [Clear All Tasks]. All queued recording tasks are cleared and the current recording is
stopped.
21.5 Loading Paper
1. Press the latch in the upper right corner of the recorder door to open it.
2. Insert a new roll into the compartment as shown below.
3. Close the recorder door.
4. Check if paper is loaded correctly and the paper end is feeding from the top.
Paper roll
