Computing the Cycle Time Section 2-7
Related Words
The average cycle time for the past eight cycles can be read from the CX-Pro-
grammer.
Note The following methods are effective in reducing the cycle time.
• Place tasks that do not need to be executed on standby.
• Use JMP-JME instructions to skip instructions that do not need to be exe-
cuted.
2-7-4 I/O Refresh Times for PLC Units
CP-series Expansion Unit and Expansion I/O Unit I/O Refresh Times
Name Addresses Description
Maximum Cycle
Time
A262 and
A263
These words contain the maximum cycle time in
increments of 0.1 ms. The time is updated every
cycle and is recorded in 32-bit binary (0 to FFFF
FFFF hex, or 0 to 429,496,729.5 ms). (A263 is
the leftmost word.)
Present Cycle Time A264 and
A265
These words contain the present cycle time in
increments of 0.1 ms. The time is updated every
cycle and is recorded in 32-bit binary (0 to FFFF
FFFF, or 0 to 429,496,729.5 ms). (A265 is the
leftmost word.)
Name Model I/O refresh time per Unit
Expansion I/O Units CP1W-40EDR
CPM1A-40EDR
0.39 ms
CP1W-40EDT
CPM1A-40EDT
0.39 ms
CP1W-40EDT1
CPM1A-40EDT1
0.39 ms
CP1W-32ER 0.33 ms
CP1W-32ET
CP1W-32ET1
0.33 ms
CP1W-20EDT
CPM1A-20EDT
0.18 ms
CP1W-20EDT1
CPM1A-20EDT1
0.18 ms
CP1W-16ER
CPM1A-16ER
0.25 ms
CP1W-16ET
CP1W-16ET1
0.25 ms
CP1W-8ED
CPM1A-8ED
0.13 ms
CP1W-8ER
CPM1A-8ER
0.08 ms
CP1W-8ET
CPM1A-8ET
0.08 ms
CP1W-8ET1
CPM1A-8ET1
0.08 ms
Analog Input Units CP1W-AD041
CPM1A-AD041
0.61 ms
Analog Output Units CP1W-DA041
CPM1A-DA041
0.33 ms
Analog I/O Units CPM1A-MAD01 0.29 ms
CP1W-MAD11
CPM1A-MAD11
0.32 ms
