High-speed Counters Section 5-2
5-2-6 Pulse Input Connection Examples
Encoders with 24 VDC Open-collector Outputs
This example shows how to connect an encoder that has phase-A, phase-B,
and phase-Z outputs.
X/XA CPU Unit
Phase A
Black
Phase B
White
Phase Z
Orange
+Vcc
Brown
0 V
(COM)
Blue
24-VDC power supply
0 V
+24 V
Encoder
(Power: 24 VDC)
Example: E6B2-CWZ6C
(NPN open-collector
output)
008 (High-speed counter 0: Phase A, 0 V)
(Differential Input Mode)
009 (High-speed counter 0: Phase B, 0 V)
003
COM
(High-speed counter 0: Phase Z, 0 V)
(COM 24 V)
008
009
003
COM
0 V
24 V
Power
0 V
Encoder
Power supply
−
Shielded twisted-pair cable
(Do not use the same power supply as for other I/O.)
IA
IB
IZ
Phase A
Phase B
Phase Z
+
CPU Unit
