Part Names Section 8-3
8-3 Part Names
Operation Button
Backlight
a
LCD
b
Front
Back
Corner Cut
Connector
c
d
e
ESC
OK
No. Button Function
a ESC
Cancel the setting and return to the up-level menu.
bForward
Move the column cursor.
Press and hold the button, the column cursor will move for-
ward continuously.
cUp
Move the line cursor up. Change numerals and parameters.
Press and hold the button, the line cursor will move up contin-
uously and the parameters will increase continuously.
dDown
Move the line cursor down. Change numerals and parame-
ters.
Press and hold the button, the line cursor will move down
continuously and the parameters will decrease continuously.
eOK
Confirm the setting.
ESC
OK
Color Meaning
Green PLC is normal.
Red PLC error has occurred.
