Omron CP1H CPU User Manual

253
Pulse Outputs Section 5-3
Differences between Set Frequencies and Actual Frequencies
5-3-5 Origin Search and Origin Return Functions
The CP1H CPU Units have two functions that can be used to determine the
machine origin for positioning.
1,2,3... 1. Origin Search
The ORG instruction outputs pulses to turn the motor according to the pat-
tern specified in the origin search parameters. As the motor turns, the ori-
gin search function determines the machine origin from the following 3
kinds of position input signals.
• Origin input signal
• Origin proximity input signal
• CW limit input signal and CCW limit input signal
• Port 0/1 (Source clock frequency: 20 MHz) • Port 2/3 (Source clock frequency: 16.4 MHz)
Set frequency (kHz) Actual frequency (kHz) Set frequency (kHz) Actual frequency (kHz)
20 975.609 to 1000.000 1000.000
21 930.232 to 975.609 952.380
22 888.888 to 930.232 909.090
::
39 506.329 to 519.480 512.820
40 493.827 to 506.329 500.000
41 481.927 to 493.827 487.804
::
99 201.005 to 203.045 202.020
100 199.004 to 201.005 200.000
101 197.044 to 199.004 198.019
::
200 99.750 to 100.250 100.000 164 99.696 to 100.000 100.000
201 99.255 to 99.750 99.502 165 99.093 to 99.696 99.393
202 98.765 to 99.255 99.009 166 98.498 to 99.093 98.795
:: ::
399 50.062 to 50.188 50.125 327 50.076 to 50.229 50.152
400 49.937 to 50.062 50.000 328 49.923 to 50.076 50.000
401 49.813 to 49.937 49.875 329 49.772 to 49.923 49.848
:: ::
999 20.010 to 20.030 20.020 819 20.012 to 20.036 20.024
1000 19.990 to 20.010 20.000 820 19.987 to 20.012 20.000
1001 19.970 to 19.990 19.980 821 19.963 to 19.987 19.975
:: ::
1999 10.002 to 10.007 10.005 1639 10.003 to 10.009 10.006
2000 9.997 to 10.002 10.000 1640 9.996 to 10.003 10.000
2001 9.992 to 9.997 9.995 1641 9.990 to 9.996 9.993
:: ::
3999 5.000 to 5.001 5.001 3279 5.000 to 5.002 5.001
4000 4.999 to 5.000 5.000 3280 4.999 to 5.000 5.000
4001 4.998 to 4.999 4.998 3281 4.997 to 4.999 4.998
:: ::
6663 3.001 to 3.001 3.001 5464 3.001 to 3.001 3.001
6665 3.000 to 3.000 3.000 5466 3.000 to 3.000 3.000
6668 2.999 to 2.999 2.999 5468 2.998 to 2.999 2.999
