Omron CP1H CPU User Manual

714
PLC Setup Appendix G
Settings: CPU Unit Settings
Execute Process Settings
Background Execution Settings
Comms Instructions Settings in FB:
Settings for Communications Instructions in Function Blocks
Name Default Settings When setting is read
by CPU Unit
Internal
address
Bits Settings
1 Do not detect Low Bat-
tery (run without battery)
Detect. Detect Every cycle 128 15 0
Do not detect. 1
2 Detect Interrupt Task
Error
Detect. Detect Every cycle 128 14 0
Do not detect. 1
3 Stop CPU on Instruction
Error
Do not stop. Do not stop. At start of operation 197 15 0
Stop 1
4 Don't resister FAL to
error log
Register. Register. Every cycle 129 15 0
Do not register. 1
Name Default Settings When setting is read
by CPU Unit
Internal
address
Bits Settings
1 Table data process
instructions
Do not execute
in background.
Do not execute in back-
ground. Execute in back-
ground.
At start of operation 198 15 0
1
2 String data process
instructions
Do not execute
in background.
Do not execute in back-
ground. Execute in back-
ground.
At start of operation 198 14 0
1
3 Data shift process
instructions
Do not execute
in background.
Do not execute in back-
ground. Execute in back-
ground.
At start of operation 198 13 0
1
4 Com Port number (logi-
cal number)
Port 00 0: Port 0
:
7: Port 7
At start of operation 198 00 to
03
0 hex
:
7 hex
Name Default Settings When setting is read
by CPU Unit
Internal
address
Bits Settings
1 Retry Counts:
Number of retries
0 0 to 15 At start of operation 200 00 to
03
0 hex
:
F hex
2 Response Timeout
(default 2s), Comms
Instructions in FB
2 s 2 s At start of operation 201 00 to
15
0000 hex
1: 1 × 0.1 s 0001 hex
: :
65535: 65,535 × 0.1 s FFFF hex
3 Response Timeout
(default 2s), DeviceNet
Comms Instruction in FB
2 s 2 s At start of operation 202 00 to
15
0000 hex
1: 1 × 0.1 s 0001 hex
: :
65535: 65,535 × 0.1 s FFFF hex
