510
LCD Option Board Function Section 8-6
8-6-13 PLC Cycle Time
This function can display the cycle time of the CPU Unit. The operation
method will be shown in the following example.
1,2,3...
1. Switch to the Setup Mode.
2. Press the Down button to select Other.
3. Press the OK button to enter the Other menu.
4. Press the OK button to enter the Cycle Time Screen.
The average cycle time of the CPU Unit will be displayed.
5. Press the Down button to display the max. cycle time of the CPU Unit.
6. Press the Down button to display the min. cycle time of the CPU Unit.
To Next Page
