367
Memory Cassette Functions Section 6-5
The areas for storing various types of data have fixed allocations in the Mem-
ory Cassette, and a single Memory Cassette corresponds to a single CPU
Unit.
Therefore it is not possible to simultaneously store multiple items of the same
type of data (e.g., two user programs).
Also, the data can only be read to a CPU Unit. It cannot be directly managed
from a personal computer like files.
The only data that can be stored on a Memory Cassette is the data from a
CPU Unit. Even when a CJ-series Special I/O Unit or CPU Bus Unit is con-
nected using a CJ Unit Adapter, any data that is stored on those Units them-
selves cannot be stored on a Memory Cassette.
Note The CX-Programmer's function for saving DM initial values is used for saving
the values in the DM Area (D0 to D32767) to the built-in flash memory as ini-
tial values. By means of a setting in the PLC Setup, these initial values can
then be automatically written to the DM Area (D0 to D32767) when the power
is turned ON.
6-5-2 Mounting and Removing a Memory Cassette
Mounting
1,2,3... 1. Turn OFF the power supply to the PLC.
2. Holding the Memory Cassette with the side with the nameplate facing up-
wards, insert the Memory Cassette all the way into the slot.
Comment data
for user pro-
grams
Variable tables Built-in flash memory (Com-
ment Memory Area)
(I/O comments, rung com-
ments, program comments)
Built-in flash memory (Com-
ment Memory Area)
Program indexes (section
names, section comments,
program comments)
Built-in flash memory (Com-
ment Memory Area)
Function Block (FB) sources Built-in flash memory (FB
Source Memory Area)
DM Built-in RAM (D0 to D32767 in
DM Area)
DM initial values (See note.) Built-in flash memory (DM Ini-
tial Values Area)
Data stored on Memory Cassette Location in CPU Unit
S
Y
S
M
A
C
C
P
1
H
IN
BATTERY
A
C
1
0
0-2
4
0
V
0
C
H
1
C
H
101CH
100CH
D
C
2
4
V
0
.3
A
O
U
T
P
U
T
E
X
P
L1 L2/N COM 01 03 05 07 09 11 01 03 05 07 09 11
00 02 04 06 08 10 00 02 04 06 08 10
00 01
02 03 04 06 00 01 03 04 06
COM COM COM COM 05 07 COM 07 COM 05 07
OUT
P
O
W
E
R
E
R
R
/A
L
M
B
K
U
P
R
U
N
IN
H
P
R
P
H
L
PERIPHERAL
M
E
M
O
R
Y
To Next Page
