SM 13 D163

1.3 G3 INTERFACE UNIT TYPE M4 (D167)

This G3 interface unit option is used only for Fax Option Type M4 (D167).

1.3.1 COMPONENT CHECK

Check the quantity and condition of the components against the following list.

No. Description Q'ty

1 SG3 Interface Unit 1

2 Screw: M3x6 3

3 Flat Cable 1

4 Telephone Cable (NA only) 1

- Harness Clamp 2

- Ferrite Core 1

- EMC Address Decal (EU only) 1

- FCC Decal (NA only) 1
