SM 207 D163
5.4 FAX COMMUNICATION FEATURES
5.4.1 MULTI-PORT
When the optional extra G3 Interface Unit is installed, communication can take place at the same
time through the two or three lines at once.
Option Available Line Type
Available protocol
Combinations
Standard only PSTN G3
Extra G3 Interface Unit (single) PSTN + PSTN G3 + G3
Extra G3 Interface Unit
(double)
PSTN + PSTN +PSTN G3 + G3 +G3
5.4.2 DOCUMENT SERVER
The base copier's scanner scans the original at the selected resolution. The IPU video processes
the data and transfers it to the controller board.
Then the controller stores the data in the page memory for the copier function, and compresses
the data in MMR (by software) to store it in the HDD. If image rotation will be done, the image is
rotated in the page memory before compression.
