Installation Requirements
SM 2-1 D146/D147/D148/D149/D150
2. INSTALLATION
2.1 INSTALLATION REQUIREMENTS
2.1.1 ENVIRONMENT
Temperature Range: 10°C to 32°C (50°F to 90°F)
Humidity Range: 15% to 80% RH
Ambient Illumination: Less than 1,500 lux (do not expose to direct sunlight.)
Ventilation: Room air should turn over at least 30 m3/hr/person
1. Avoid areas exposed to sudden temperature changes:
1) Areas directly exposed to cool air from an air conditioner.
2) Areas directly exposed to heat from a heater.
2. Do not place the machine where it will be exposed to corrosive gases.
3. Do not install the machine at any location over 2,000 m (6,500 ft.) above sea level.
(D135 for NA can be installed only up to 2,500m (8,202 ft.))
4. Place the main machine on a strong and level base. Inclination on any side should
be no more than 5 mm (0.2").
5. Do not place the machine where it may be subjected to strong vibrations.
