ADF Removal
SM 1 D683
SPDF DF3080
(D683)
1. REPLACEMENT AND ADJUSTMENT
1.1 ADF REMOVAL
1. Controller cover [A] ( ×4)
2. Rear cover [A] (
×4)
3. Scanner rear cover [A] ( ×3)
4. Scanner rear cover (small) [A] ( ×2)
