Ricoh D148 User Manual (English)

To Next Page

To Previous Page

Tray Set Switch (Right)

SM 11 D695

LCIT PB3170

(D695)

1.9 TRAY SET SWITCH (RIGHT)

1. Right tray ( page 2)

2. Rear cover (

page 1)

3. Tray set switch (right) [A] (

×1)
