Electrical Component Defects

D146/D147/D148/D149/D150 5-214 SM

5.12 ELECTRICAL COMPONENT DEFECTS

5.12.1 D148/D149/D150

Name Output connector

Capacity Part number

Can be changed in

the field or not

Voltage Part name Remarks

FU101

CN985 (Fusing center

heater)

CN986 (Fusing edge heater)

15A 11071241 Yes

AC TLC-15A-N4

Installed on AC

control board

FU102 CN988 (DC power supply)

15A 11071241 Yes

AC TLC-15A-N4

Installed on AC

control board

FU3 CN912(IOB, SIO)

10A 11071216 Yes

24V

FBT 250V

10A(EM)

Installed on DC

power supply

FU4

CN917 (Interlock switch

[IOB])

10A 11071216 Yes

24V

FBT 250V

10A(EM)

Installed on DC

power supply

FU5

CN917 (Interlock switch

[IOB])

10A 11071216 Yes

24V

FBT 250V

10A(EM)

Installed on DC

power supply

FU7

CN913(FIN)

CN914(BANK)

10A 11071216 Yes

24V

FBT 250V

10A(EM)

Installed on DC

power supply
